Very Narrow Aisle Racking Dimensions

A very narrow aisle turret truck uses an aisle of 10 inches to 18 inches wider than the width of the lift truck assuming a 48 inch length x 40 inch width load.

Very narrow aisle racking dimensions. Order picker order selector stock picker. With different warehouse layouts it is used for very narrow aisle rack drive in rack double deep rack carton flow rack and shuttle pallet rack etc. These pallet rack systems are available in original slotted or tear drop style columns and can be used at. In very narrow aisle vna pallet rack systems the space separating parallel rack units is greatly reduced and pallets are placed and retrieved using a side loading fork truck.

Revit pallet rack teardrop type is widely used in a variety of storage applications. Special lift trucks equipped with a rotation fork turret vna trucks required in such confined spaces. Pallet racks placed close to one another. Very narrow aisle pallet racking requires the use of specialised narrow aisle forklift trucks that can manoeuvre between the narrow aisles.

Narrow aisle racking reduces the width of aisles between lanes by up to half compared to standard pallet storage solutions and provides a solution for highly dense areas. While handling a standard 48 pallet you require an approximately 11 foot wide aisle for storing and retrieving pallets in a standard racking system. Maximized storage capacity vertically and horizontally. Clear aisles can be as narrow as 66 inches 5 5 feet.

Very flat floors close tolerance racking carefully located pallets of uniform size and stock locationg systems are all prerequisites for successful narrow aisle systems. 1 8 m to 2 0 m. Very narrow aisle racking. The very affordable walkie designs can provide narrow aisle functionality to even the smallest warehouses and storage areas.

The most significant difference between vna trucks and all others is that vna trucks turn only the load while wide aisle and narrow aisle trucks must turn the entire vehicle in the aisle. Floor guidance in the aisles is mandatory and the design interface between every aspect of their system is needed. When it comes to maximising warehouse capacity or storage areas our narrow aisle pallet racking systems also known as very narrow aisle racking vna is an extremely practical and popular option. This minimizes the size of the aisles between rows of racks and can reduce the aisle space by around 40.

Very narrow aisle racking. Aisle dimensions for narrow aisle stand up counterbalanced forklifts. Man up or man down articulated or flexi trucks are used to ensure precision in facilities using very narrow aisle pallet racking.
